4/0 Gauge AWG Ultra Flexible Welding Battery Copper Cable Wire

4/0 AWG Cable is designed to meet and exceed stringent specifications. This UL-approved cable is manufactured in-house in Sarasota FL, USA for the highest level of quality. Many times, marine installations take place in enclosed spaces that have sharp turns. Installation can quickly become difficult. Pacer Group has made the installation of battery cables much easier. This 4/0 AWG  battery cable is able to easily handle the toughest environments.The copper resists corrosion while helping to extend the life of the cable. The cable is then insulated with a flexible and durable PVC jacket. These things work together to make the highest quality marine cable available.

FEATURES:

Easy to strip, bend, and route

Excellent flexibility with the durable properties of PVC

COMPLIANCES:

UL Standard 1426 BC-5W2

AWM 1232/1284

MTW

CSA: TEW

ABYC: E-11.16

Coast Guard: 33 CFR part 183 Subpart 1

CHARACTERISTICS:

Conductor: Annealed fine stranded tinned copper ASTM B172 Class K

Insulation: -20 °C to 105 °C Flexible, Color Coded PVC

Temperature Rating: 105 °C Dry, 75 °C Wet, 60 °C Oil

Voltage Rating: 600-V

Resistant to: Acid, Alkali, Abrasion, Flame, Gasoline, Oil and Moisture

PRINT:

PACER E157097 (UL) 4/0AWG 600V BC-5W2 105°C DRY, 75°WET OR MTW OR AWM 1232/1283 VW-1 OIL RESISTANT I LL102583 CSA TEW 105°C FT1

APPLICATIONS:

Connecting battery or generator to a starter, ground, switch, windlass, inverter, or other high amperage equipment
